Description
• 230/240v 50Hz Single Phase 4 Pole
• Genuine S & P Fan With 12 Month Manufacturers warranty
• Suitable for Extraction of a Canopy or Can Be Used For Air Intake
• Manufactured from High Grade rolled galvanised steel with black polyester finish
• Supplied with a pre-wired, wiring junction box located on outside of fan case for easy wiring, Cable Gland PG-11
• Dynamically Balanced Impeller to ISO 1940 Standard
• Speed Controllable
• Corrosion Resistant
• IP44 Rated Class F Thermal Protection
• Working Temperature -40 c to +70 c
• *Please note the manufacturer of these fans are now in transition of changing the impeller blades from red to black.
Optional speed controller available: REB-5
Available Sizes (WxDxH)
• 250mm⌀ – TCBB/4-250/H
• 315mm⌀ – TCBB/4-315/H
• 355mm⌀ – TCBB/4-355/H
• 400mm⌀ – TCBB/4-400/H
• 450mm⌀ – TCBB/4-450/H
• 500mm⌀ – TCBB/4-500/H
• 560mm⌀ – TCBB/4-560/H
• 630mm⌀ – TCBB/4-630/H
